How does a nitrogen compressor work

nitrogen compressors are suitable for: nitrogen generator matching, oxygen generator matching, chemical industry, food, rubber, grain, oil and food, cigarette and wine, aquaculture, mechanical metallurgy, petrochemical, textile printing and dyeing, electronic equipment, transportation and telecommunications, scientific research institutions and other departments that need to purify the air source.

• How does a nitrogen compressor work?

• What are the characteristics of nitrogen compressor?

• What are the precautions for using nitrogen compressor?

How does a nitrogen compressor work?

The nitrogen compressor is an oil-free, reciprocating piston, single-acting, air-cooled compressor, designed for industries that require a clean air source and higher environmental requirements; this machine can further pressurize the lower pressure nitrogen to make Its pressure can meet the needs of industrial production, and it has a closed structure, leak-free operation, low noise and stable operation. Industries that require pure, high-pressure gas can use nitrogen compressors.

What are the characteristics of nitrogen compressor?

The nitrogen compressor is completely oil-free, green and pollution-free, and does not need to be lubricated. The friction seals such as piston rings and guide rings of the nitrogen compressor are made of special materials with self-lubricating properties, which do not affect the gas composition

The structural advantages are reflected in:

1. Nitrogen compressor The entire compression system is not lubricated by thin oil, avoiding the possibility of oil contacting with high pressure and high purity nitrogen

2. The whole system of nitrogen compressor has simple mechanical structure, convenient control and convenient operation;

3. The nitrogen compressor has no pollution for the compressed gas medium, and the purity of nitrogen at the inlet and outlet of the compressor is the same.

What are the precautions for using nitrogen compressor?

1. The nitrogen compressor should use a lifting device with a bearing capacity greater than the weight of the unit, and its hoisting speed and acceleration should be limited within the allowable range.

2. Try to install the nitrogen compressor in a cool, clean and well-ventilated place to ensure that the air sucked by the compressor is clean and has the lowest moisture content.

3. The air inhaled by the nitrogen compressor must not contain flammable gas and corrosive gas, so as to avoid explosion or internal rust.

4. It is better for the air cooler to have an exhaust fan or an air duct to discharge the hot air outside to prevent the hot air from circulating into the tuyere.

5. The discharge of waste water and waste oil from the nitrogen compressor must comply with the regulations of the local environmental protection department.

6. The nitrogen compressor uses a three-phase AC power supply of 380V, 50Hz. The power supply line of the bleed air compressor must be equipped with air switches, fuses and other safety devices to ensure the reliability and reliability of the electrical equipment, and must be reliably grounded.

7. The normal use of nitrogen compressor is inseparable from clean compressed air, so it is very important to use the compressor correctly.
