industrial hydrogen 700bar diaphragm compressor cylinder filling manufacturers

descrizione

hydrogen 700bar diaphragm compressor cylinder filling, is a reciprocating compressor that reciprocates in a cylinder to compress and transport gas.
The cylinder filling diaphragm nitrogen compressor is a special type of volumetric compressor with large compression ratio, good sealing performance, and the compressed gas is not polluted by lubricating oil and other solid impurities. Therefore, it is suitable for compressing high purity, rare and precious, flammable, explosive, toxic and harmful, corrosive and high pressure gases.

cylinder filling hydrogen 700bar diaphragm compressor , are one of many types of compressors. It has a special name because it has a special diaphragm that separates the compressed medium from the outside. The diaphragm compressor can also be referred to simply as a membrane compressor. Due to its special structure, the oxygen reciprocating low pressure diaphragm compressor does not need lubrication, and the sealing performance is very good. The compressed medium is not in contact with any slip agent, so it can compress the gas with very high purity, generally achieving a purity of 99.999%, which is more suitable for compression. And transport all kinds of precious rare gases. In addition, for corrosive, radioactive, toxic, and explosive gases, diaphragm compressors are also particularly suitable. The diaphragm compressor has good heat dissipation and can adopt a high compression ratio, so its pressure range is wide, and the exhaust pressure can be up to 500MPa. It is used in the food industry, petroleum industry chemical industry, electronics industry, nuclear power plant, aerospace, military equipment, medicine, scientific research and other fields.

G4 industrial membrane electric hydrogen compressor  |nitrogen compressor|is a non-standard compressor product, G4 diaphragm compressor is divided into single cylinder GZ4and double cylinder GL4 and GD4 diaphragm compressor, G4 diaphragm compressor piston force 8TON, Customized according to different customer parameters, requirements and environment!
GZ4 hydrogen cylinder filling compressor 700bar diaphragm manufacturers is composed of cylinder block, cylinder head, crankshaft connecting rod, diaphragm, oil circuit, gas path, water cooling system and motor drive. The G4 and G4 diaphragm compressor series products are available from our company. Cooling method: air cooling and water cooling.
Company product features
Ø Advanced oil-free disc cylinder component structure reduces the difficulty of assembly process; reduces sealing surface; alarm when leakage medium leaks, improves the reliability of the whole machine.
Ø The oil consumption of the whole machine hydraulic oil is small, which is 1/2 of the oil used in the traditional diaphragm compressor. The economic advantage is very obvious for the oxygen compressor.
Ø New membrane cavity curve, Kezan
Nie or HOERBIGER's air valve,
Leading diaphragm surface treatment technology
Improves the work of the compressor
Efficiency, achieving high energy efficiency,
Moreover, the life of the vulnerable piece diaphragm and the air valve is improved. Diaphragm and air valve have a guaranteed average life of 3000
Hours and 6,000 hours or more.
Ø Full-featured built-in oil supply and pressure regulation system for compressor lubrication and oil
Cylinder work provides pressure stable, clean quality lubricants and oils
The road system does not leak, completely different from the traditional diaphragm compressor oil system.
It belongs to our company's patented technology.
Ø User-friendly instrument interface and middle window, simple oil and gas pipeline.

Characteristics of G4 series hydrogen cylinder filling compressor 700bar diaphragm industrial manufacturers
Compact structure, is a large diaphragm compressor
Structure type, D type (two cylinder, three cylinder or four cylinder)
Lubrication method
Replenishment method
Cooling method, water cooling
Repair single piece maximum weight: 2500kg
Maximum maintenance space: no less than 1.5 meters around

Model	Flow Rate Nm3/hr	Suction Pressure .Mpa	Discharge pressure.Mpa	Water Consumption L/hr	Speed .rpm	Motor.KW	Dimension L*W*H mm	Weight kgs
GD4-90/200	90	常压	20	4000	400	45	3800x2800X1650	12.8
GD4-100/160	100	常压	16	4000	400	45	3800X2800X1650	12.8
GD4-240/6-150	240	0.6	15	6500	400	75	3500X2300X1600	8.6
GD4-190/16-300	190	1.6	30	5000	3600	55	3500X2300X1500	7.8
GD4-400/12-210	400	1.2	21	6500	400	75	3500X2300X1600	8.6
GD4-600/12-40	600	1.2	4	5000	360	55	3500X2300X1600	8.6
GD4-360/15-210	360	1.5	21	6500	400	75	3500X2300X1600	8.6
GD4-400/8-110	400	0.8	11	6700	400	55	3500X2300X1600	8.9
GD4-140/14-500	140	1.4	50	6000	400	75	3500X2300X1500	7.8
GD4-200/4-160	200	0.4	16	6500	400	75	3500X2300X1600	8.6
GD4-300/4.5-140	300	0.45	14	6000	400	75	3500X2300X1600	8.5
GD4-450/11-100	450	1.1	10	6500	400	75	3500X2300X1600	8.5
GD4-1000/14-50	1000	1.4	5	6500	400	75	3500X2300X1600	8.2
GD4-300/0. 11-6	300	0.011	0.6	4000	420	45	3800X3200X1900	13
GD4-180/2-200	180	0.2	20	6500	400	75	3500X2300X1600	8.6
GD4-600/15-350	600	1.5	35	12000	400	160	4000X2400X2000	9.8
GD4-1000/7-150	1000	0.7	15	18000	400	200	4000X2400X2000	10.6
GD4-7340/66—87	7340	6.6	8.8	8000	420	110	3500X2800X1900	9.8
